| Technical Details | |
| Connections | EIB/KNX |
| Power Supply | DC 21V-30V |
| Bus Current | <12mA |
| Bus Consumption |
<360mW
|
| Auxiliary Voltage | DC 21V-30V |
| Auxiliary Current | <33mA (30VDC)；
<45mA (24VDC)
|
| Auxiliary Consumption | <1W |
| Temperature Setting Range | 16~30℃ |
| Temperature Display Accuracy | ±0.1℃ |
| Humidity Display Range | 0~100％ |
| Working Temperature | -5℃ - +45℃ |
| Storage Temperature | -25℃ to +55℃ |
| Working Humidity | <93%RH (Non-condensing) |
| Dimension | 86 x 86 x 38.2 mm |
| Installation | Flush Mounting |
| Flush Mounted Module | EU/UK/GB Standard |
-
Datasheet 904M-S3.pdfDownload
