| Technical Details | |
| Connection | KNX |
| Power Supply | DC 21V-30V |
| Dry Contact Input | 6 Inputs |
| Relay Output | 3 Channels, 10A/Channel (AC 100–240V, 50/60Hz) |
| LED Output |
6 Channels, 1mA/Channel
|
| Bus Current | 6mA/30VDC |
| Working Temperature | -5℃ - +45℃ |
| Storage Temperature | -20℃ to +60℃ |
| Working Humidity | <90%RH (Non-condensing) |
| Dimension | 49.3 x 49.3 x 22.5 mm |
| Installation | Flush Mounting |
| Flush Mounting Box | EU/UK/GB Standard |
-
Datasheet 904M-S3.pdfDownload
