905D-Y4

7” Facial Recognition Android Doorphone

·7” capacitive touch screen

·Visible light face recognition

·Dual 2MP HD cameras with IR support

·Anti-spoofing algorithm against photos and videos

·Support multiple access control methods: facial recognition, 13.56MHz/125kHz access cards

·Up to 10000 faces, and 100000 cards can be added

·Quick to install and easy integration with IP telephone systems using SIP protocol support

  • Product Detail
Y-4icon_画板 1
Y-4icon_画板 1 副本 2
Y-4icon_画板 1 副本 3
Y-4icon_画板 1 副本

 Physical Property
  System  Android 6.0.1
  CPU   Quad-core Cortex-A17 1.8GHz  Integrate Mali-T764 GPU
  SDRAM  2GB DDR3
  Flash  8GB NAND Flash
  Display  7“ TFT LCD, 1920*1080
  Face Recognition  Yes(optional)
  Power  DC12V/PoE (External Module)
  Standby power  5W
  Rated Power  25W
  RFID Card Reader  IC/ID, 100,000 pcs
  Temperature  -40℃ - +70℃
  Humidity  20%-93%
  IP Class  IP65
  Size  227*122*20 mm
  Multiple Installation  Surface mounted
 Audio & Video
  Audio Codec  G.711, G.729
  Video Codec  H.264
  Camera  CMOS 2M pixel
  LED Night Vision  Yes(6pcs)
 Network
  Ethernet  10M/100Mbps, RJ-45
  Protocol  TCP/IP,  SIP,  RTSP
 Interface
  Relay output  Yes
  Exit Button  Yes
  RS485  Yes
  Door Magnetic  Yes



  • Datasheet 905D-Y4.pdf
    Download
