High reputation Home Intercom - 10.1” Facial Recognition Android Doorphone – DNAKE Detail:
| Physical Property | |
| System | Android |
| RAM | 512MB |
| ROM | 8GB |
| Front Panel | Aluminum |
| Power Supply | PoE (802.3af) or DC12V/2A |
| Standby Power | 3W |
| Rated Power | 13W |
| Camera | 2MP, CMOS |
| IR Sensor | Support |
| Door Entry | Face, IC card(13.56MHz), PIN code, NFC |
| IP Rating | IP65 |
| Installation | Flush mounting |
| Dimension | 400 x 180 x 45mm |
| Working Temperature | -40℃ - +55℃ |
| Storage Temperature | -40℃ - +70℃ |
| Working Humidity | 10%-90% (non-condensing) |
| Display | |
| Display | 10.1-inch TFT LCD |
| Screen | 10.1-inch capacitive touch screen |
| Resolution | 1024 x 600 |
| Audio & Video | |
| Audio Codec | G.711 |
| Video Codec | H.264 |
| Video Resolution | up to 1920 x 1080 |
| Light Compensation | LED white light |
| Networking | |
| Protocol | SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP |
| Port | |
| Wiegand Port | Support |
| Ethernet Port | 1 x RJ45, 10/100 Mbps adaptive |
| RS485 Port | 1 |
| Relay Out | 1 |
| Exit Button | 1 |
| Door Magnetic | 1 |
Product detail pictures:
Related Product Guide:
Being supported by an advanced and specialist IT team, we could give technical support on pre-sales & after-sales services for High reputation Home Intercom - 10.1” Facial Recognition Android Doorphone – DNAKE, The product will supply to all over the world, such as: Azerbaijan, Estonia, UAE, Our staffs are rich in experience and trained strictly, with professional knowledge, with energy and always respect their customers as the No. 1, and promise to do their best to provide the effective and individual service for customers. The Company pays attention to maintaining and developing the long-term cooperation relationship with the customers. We promise, as your ideal partner, we will develop a bright future and enjoy the satisfying fruit together with you, with persisting zeal, endless energy and forward spirit.
-
Datasheet 904M-S3.pdfDownload
