| Technical Details | |
| Connections | EIB/KNX |
| Power Supply | DC 21V-30V |
| Output | 28 Channels |
| Dry Contact Input | 28 Inputs |
| Output Rated Voltage | 250V AC (50/60Hz) |
| Output Rated Current | 10A (Resistive Load) |
| Working Temperature | -5℃ - +45℃ |
| Storage Temperature | -25℃ to +55℃ |
| Working Humidity | <93%RH (Non-condensing) |
| Dimension | 216 x 90 x 64 mm |
| Installation | 35mm DIN Rail Mounting |
-
Datasheet 904M-S3.pdfDownload
