| Technical Details | |
| Connection | KNX |
| Power Supply | 12~24VDC |
| Operating Current | <50mA @ 24V DC |
| RF Frequency | 24.00 – 24.25GHz |
| Motion Sensing Distance | 1.5 – 4 m |
| Presence Detection Distance | 1 – 3 m |
| Illuminance Measuring Range | 0 – 65535 Lux (1Lux ~ 60kLux) |
| Delay Time | 0 – 7200s |
| Working Temperature | -5℃ - +45℃ |
| Storage Temperature | -25℃ to +55℃ |
| Working Humidity | <93%RH (Non-condensing) |
| Dimension |
Φ67 mm
|
| Installation | Ceiling Mounting |
-
Datasheet 904M-S3.pdfDownload
