Outdoor Intercom System - 290 Slave – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290A isolator or master converter using a two-wire cable.
2. It can connect and supply power to an IP device, such as villa door station with PoE function, over an Ethernet port.
3. One Ethernet port can be used for internet input and PoE power supply.
2. It can connect and supply power to an IP device, such as villa door station with PoE function, over an Ethernet port.
3. One Ethernet port can be used for internet input and PoE power supply.
| Physical Property | ||||
| Size | 112x87x25mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | NA | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Interface | DC socket (Output 12VDC)*1 RJ45*1 2-core interface*1 |
|||
| LED Indicators | Power: Red – Power ON 2-Wire: Green – Link ON LAN: Green – Link ON | |||
| Transmission Method | Access Method: CSMA/CA; Transmission Scheme: Wavelet OFDM; Frequency Bandwidth: 2 MHz to 28 MHz | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| network cable | Cat 5e, Cat 6 or better | |||
