| Physical Property | ||||
| Frame | Aluminum Alloy | |||
| Front Panel | Tempered Glass | |||
| Camera | 2MP,1080P | |||
| Power Supply | PoE or DC 12V | |||
| RFID Reader |
13.56MHz and 125kHz
|
|||
| Door Entry | RFID, PIN, NFC, Bluetooth, QR Code, APP | |||
| IP/IK Rating | IP65 / IK08 | |||
| Installation | Flush Mounting & Surface Mounting | |||
| Dimension | 137 x 50 x 27 mm | |||
| Working Temperature | -40℃ - +55℃ | |||
| Storage Temperature |
-40℃ to +70℃
|
|||
| Working Humidity | 10%-90% (non-condensing) | |||
| Networking |
||||
| Protocol |
IPv4, HTTP, DNS, NTP, TCP, UDP, ICMP, DHCP, ARP
|
|||
| Port |
||||
| Input | 2 | |||
| Output | 1 Relay | |||
| Wiegand | Support | |||
| RS485 | Support | |||
| Ethernet Port | 1 x RJ45, 10/100 Mbps adaptive | |||
-
Datasheet 904M-S3.pdfDownload
