Smart Home Intercom System - 2-Wire IP System Converter – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP device using a two-wire cable, even in an analog environment.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
| Physical Property | ||||
| Size | 112x87x25mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Network Cable | Cat 5e, Cat 6 or better | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| Interface | ||||
| RJ45 | YES | |||
| 2-Wire | Yes | |||
| PoE | Yes | |||
| DC Socket | Yes (Input 48VDC) | |||
| LED Indicators | ||||
| Power | Red – Power ON | |||
| 2-Wire | Green – Link ON | |||
| LAN | Green – Link ON | |||
| Transmission Method | ||||
| Access Method | CSMA/CA | |||
| Transmission Scheme | Wavelet OFDM | |||
| Frequency Bandwidth | 2 MHz to 28 MHz | |||
Product detail pictures:
Related Product Guide:
Good quality comes to start with; service is foremost; organization is cooperation" is our enterprise philosophy which is regularly observed and pursued by our firm for Smart Home Intercom System - 2-Wire IP System Converter – DNAKE, The product will supply to all over the world, such as: Washington , Ecuador , Mauritius , Please feel cost-free to send us your specifications and we'll respond to you asap. We've got a professional engineering team to serve for the every single detailed needs. Free samples may be sent for you personally to know far more facts. So that you can meet your desires, please really feel cost-free to contact us. You could send us emails and call us straight. Additionally, we welcome visits to our factory from all over the world for much better recognizing of our corporation. nd merchandise. In our trade with merchants of several countries, we often adhere to the principle of equality and mutual advantage. It is our hope to market, by joint efforts, both trade and friendship to our mutual benefit. We look forward to getting your inquiries.
-
Datasheet 904M-S3.pdfDownload
