» Bottom price Intercom Bell – 290AB – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP devices using two-wire cables, even in an analog environment.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
| Physical Property | ||||
| Size | 197x114x38mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Interface | DC socket (Input 48VDC)*1 2-core interface(Main In)*1 2-core interface(Main Out)*1 2-core interface(connect to indoor monitor)*8 |
|||
| LED Indicators | red light always on-2WIRE connection status | |||
| Transmission Method | Access Method: CSMA/CA；Transmission Scheme:Wavelet OFDM；Frequency Bandwidth: 2 MHz to 28 MHz | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| network cable | NA | |||
Product detail pictures:
Related Product Guide:
We now have a skilled, performance team to supply good quality services for our consumer. We often follow the tenet of customer-oriented, details-focused for » Bottom price Intercom Bell – 290AB – DNAKE, The product will supply to all over the world, such as: Slovakia , Canberra , Indonesia , Customer satisfaction is our goal. We are looking forward to cooperating with you and providing our best services for you. We warmly welcome you to contact us and please feel free to contact us. Browse our online showroom to see what we can do for you. And then E-mail us your specifications or inquiries today.
-
Datasheet 904M-S3.pdfDownload
