| Pfuma Yenyama | |
| System | Android |
| RAM | 1GB |
| ROM | 4GB |
| Front Panel | Plastiki |
| Magetsi | PoE (802.3af) kana DC12V/2A |
| Standby Power | 3W |
| Rated Power | 10W |
| Wi-Fi | IEEE802.11 b/g/n,@2.4GHz (Zvichida) |
| Kamera | 0.3MP, CMOS (Sarudzo) |
| Installation | Surface mounting |
| Dimension | 221.4 x 151.4 x 16.5mm |
| Kushanda Tembiricha | -10 ℃ - +55 ℃ |
| Storage Temperature | -40 ℃ - +70 ℃ |
| Kushanda Humidity | 10% -90% (isina-condensing) |
| Display | |
| Display | 7-inch TFT LCD |
| Sikirini | Capacitive touch screen |
| Resolution | 1024 x 600 |
| Audio & Vhidhiyo | |
| Audio Codec | G.711 |
| Video Codec | H.264 |
| Networking | |
| Protocol | SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP |
| Port | |
| TF Card Port | 1 |
| USB Port | 1 |
| Ethernet Port | 1 x RJ45, 10/100 Mbps inogadziriswa |
| RS485 Chiteshi | 1 |
| Power Output | 1 (12V/100mA) |
| Kupinza kweDoorbell | 8 (shandisa chero alarm yekupinza port) |
| Alarm Input | 8 |
-
