» Outdoor Panel – 902M-S2 – DNAKE

Spec

Product Tags

Related Video

Feedback (2)

Our organization promises all customers with the first-class products and solutions and the most satisfying post-sale service. We warmly welcome our regular and new clients to join us for Home Automation Sensors , Nurse Call Button , Outdoor Intercom , We warmly welcome mates from all walks of life to hunt mutual cooperation and develop a more good and splendid tomorrow.
» Outdoor Panel – 902M-S2 – DNAKE Detail:

1. 7-inch touch screen panel delivers brilliant display and ultimate screen experience.
2. User interface can be customized and programmed as needed.
3. The indoor monitor can use SIP2.0 protocol to establish the video and audio communication with IP phone or SIP softphone, etc.
3. Users can install any app in the indoor monitor for home entertainments.
4. Max. 8 alarm zones, such as fire detector, smoke detector, or window sensor etc., can be connected to increase home security.
5. It supports monitoring 8 IP cameras in the surrounding environment, such as the garden or parking lot, to keep your home safe and secure.
6. When it integrates with smart home system, you are able to control and manage home appliances with the indoor monitor or smartphone, etc.
7. Residents can enjoy clear audio communication with visitors and see them before granting or denying access as well as call the neighbors using the monitor.

 Physical Property
  System  Android 4.4.2
  CPU   Quad core 1.3GHz Cortex-A7
  Memory  DDR3 512MB
  Flash  4GB
  Display  7" TFT LCD, 1024x600
  Power  DC12V
  Standby power  3W
  Rated Power  10W
  TF Card &  USB Support  Yes (Maximum 32 GB)
  WiFi & Bluetooth  Optional
  Temperature  -10℃ - +55℃
  Humidity  20%-85%
 Audio & Video
  Audio Codec  G.711U, G711A, G.729
  Video Codec  H.264
  Screen  Capacitive, Touch Screen
  Camera  Yes(Optional), 0.3M Pixels
 Network
  Ethernet  10M/100Mbps, RJ-45
  Protocol  SIP,TCP/IP, RTSP, RTP, HTTP
 Features
  IP Camera Support  8-way Cameras
  Door Bell Input  Yes
  Record  Picture/Audio/Video
  AEC/AGC  Yes
  Home Automation  Yes(RS485)
  Alarm  Yes(8 Zones)
