» Intercom Number – 290AB – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP devices using two-wire cables, even in an analog environment.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
| Physical Property | ||||
| Size | 197x114x38mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Interface | DC socket (Input 48VDC)*1 2-core interface(Main In)*1 2-core interface(Main Out)*1 2-core interface(connect to indoor monitor)*8 |
|||
| LED Indicators | red light always on-2WIRE connection status | |||
| Transmission Method | Access Method: CSMA/CA；Transmission Scheme:Wavelet OFDM；Frequency Bandwidth: 2 MHz to 28 MHz | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| network cable | NA | |||
Product detail pictures:
