» Intercom Box – 290AB – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP devices using two-wire cables, even in an analog environment.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
| Physical Property | ||||
| Size | 197x114x38mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Interface | DC socket (Input 48VDC)*1 2-core interface(Main In)*1 2-core interface(Main Out)*1 2-core interface(connect to indoor monitor)*8 |
|||
| LED Indicators | red light always on-2WIRE connection status | |||
| Transmission Method | Access Method: CSMA/CA；Transmission Scheme:Wavelet OFDM；Frequency Bandwidth: 2 MHz to 28 MHz | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| network cable | NA | |||
Product detail pictures:
Related Product Guide:
We provide fantastic energy in top quality and advancement,merchandising,gross sales and marketing and operation for » Intercom Box – 290AB – DNAKE, The product will supply to all over the world, such as: India , Croatia , Guatemala , Now, with the development of internet, and the trend of internationalization, we have decided to extend business to overseas market. With the propose of bringing more profits to oversea customers by providing directly abroad. So we have changed our mind, from home to abroad, hope to give our customers more profit, and looking forward to more chance to make business.
-
