» 2-Wired Apartment Intercom – IP System Isolator – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP devices using two-wire cables, even in an analog environment.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
| Physical Property | ||||
| Size | 197x114x38mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Network Cable | NA | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| Interface | ||||
| 2-Wire | Main In*1 Main Out*1 Connection to indoor monitor*8 |
|||
| DC Socket | Yes(Input 48VDC) | |||
| Transmission Method | ||||
| Access Method | CSMA/CA | |||
| Transmission Scheme | Wavelet OFDM | |||
| Frequency Bandwidth | 2 MHz to 28 MHz | |||
Product detail pictures:
Related Product Guide:
We take "customer-friendly, quality-oriented, integrative, innovative" as objectives. "Truth and honesty" is our administration ideal for » 2-Wired Apartment Intercom – IP System Isolator – DNAKE, The product will supply to all over the world, such as: United States , Czech , Belarus , Honest to every customers are our requested! First-class serve, best quality, best price and fastest delivery date is our advantage! Give every customers good serve is our tenet! This makes our company get the favour of customers and support! Welcome all over the world customers send us enquiry and looking forward your good co-operation !Please your inquiry for more details or request for dealership in selected regions.
-
Datasheet 904M-S3.pdfDownload
